SAE Hydraulique Flanges Flanges yu kawe- cër yi ñuy jëfandikoo ngir mëna dem ci sistem hydraulique yu bari yu am kaaraange. Bu ñu sukkandikoo ci sàrti SAE J518 ak ISO 6162, flange yooyu dañuy tax ñu mëna def liggéey bu wóor ci- aplikaasioŋ yu bari ci liggéey yu bari.
Waxtaan yi
|
PART NO. |
FLANGE SIZE |
ÑAAY WAX |
DEMANSIONS |
|||||
|
DN |
RËDD |
A |
C |
D |
H |
L |
||
|
87641-08-08 |
1/2" |
12 |
08 |
58.9 |
31.7 |
24 |
24 |
7.75 |
|
87641-08-12 |
1/2" |
20 |
12 |
74.9 |
31.7 |
24 |
27.5 |
7.75 |
|
87641-12-10 |
3/4" |
16 |
10 |
72.5 |
41.3 |
32 |
28.2 |
8.76 |
|
87641-12-12 |
3/4" |
20 |
12 |
79.2 |
41.3 |
32 |
31.8 |
8.76 |
|
87641-16-16 |
1" |
25 |
16 |
90.2 |
47.6 |
38 |
34.7 |
9.53 |
|
87641-20-20 |
1.1/4" |
32 |
20 |
103.8 |
54 |
44 |
41.5 |
10.29 |
|
87641-24-20 |
1.1/2" |
32 |
20 |
105.8 |
63.5 |
51 |
45.1 |
12.57 |
|
87641-24-24 |
1.1/2" |
40 |
24 |
116.2 |
63.5 |
51 |
45.5 |
12.57 |
|
87641-32-24 |
2" |
40 |
24 |
125.4 |
79.4 |
67 |
54.7 |
12.57 |
|
87641-32-32 |
2" |
50 |
32 |
135.7 |
79.4 |
67 |
52.7 |
12.57 |
Parametre yi/tablo yi ci wàllu xarala
|
Bu cosaan |
ZheJiang, Chine |
Bisu joxe |
Yowna |
|
Sàrtifikaa |
GB/T19001-2016 uy ISO90001:2015 |
Packing |
jaar-jaar |
|
Jumtukaay |
Carbon Steel |
muñ |
1 at |
|
Tegtal |
TT |
MOQ |
2000 |
|
Anam |
Bees |
Melni |
zinc bu weex, melo zan bu am melo |
ci wàllu liggéeyukaay
Njariñ yi
Performance bu amul benn yoon
Ingénieur moo wara def 10,000 PSI pression
30% ci pression bu gëna rëy moo gëna SAE yiñ laaj ci SAE
Defar njubte ci biir pression bu metti bu metti
Excellence
CNC dafa jëfandikoo ±0.005" ngir mëna dékku bu baax
Tabax buñ forgé (duñu ko sànni) ngir am doole bu gëna mag
Micro- ay surface yuñ tëj (Ra < 0.4μm)
Kalite Material bu mag
Aircraft- grade karbon ak bañaale coono bu gëna baax
316L tànneef asiye inox ak 5x corrosion
Togg bu mat sëkk ak sertifikaa yiñ def ci moulin yi
Leak- guarantee
Quad {- Xarala (0}}Seal TM (ñaari seal yu njëkk, ñaareel, ak ñaari seal yu am ñaari yoon)
Preformance FKM O-ringu {-65 degre F ba 65 degre F ba 4.
100% pression biñ natt ci 1.5x pression biy liggéey
Industry- Liggéey
50% ci dundu serwiis bu gëna gudd ci liggéey
Amna ay surface yu dëgër ngir mëna jëfandikoo ndoxu abrasive
Impact- na desin ci environmaa yi-y ci environmaa yi
Komplisaas ak Sàrtifikaasioŋ ci àdduna
SAE J518, ISO 6162, ak ASME B16.5
PED 2014/68/EU compliant
ABS ak DNV-GL nangu nañu ko
Instalaasioŋ yi
Laser- i ràññeekaay yu yomb ngir jubluwaay
Presalment ak tegtal
40% ci instalaasioŋ bu gëna gaaw bi flanges yiñ gëna xam
Këyitu personalisasioŋ
Amna ci yaatuwaayu 1/4" ba 6" ba 6"
Mbir yu am solo yu ci melni Monel, Hastelloy, ak titanium
configuration port personaal ak poñ pression
Kalite Kalite bu am doole
100% ci wàllu dimension ak CMM
Doxalinu ci anam wu jaarul yoon
Batch toppu ak nimero serie yu amul fenn
Jàppaleen Jàngale bu amul fenn
Ekipu ingenieur u aplikaasioŋ buñ tëral
Càmbaru sistem hydraulique bu amul fay
Ci-i tàggat sampy installation am na
